5083 is one kind of Aluminum Alloys with good performances in corrosion resistance, weldabillity and formability. 5083 alloy especially works well in sea and industrial atmospheric corrosion environment, which makes it popular used in marine and relevant industries under low temperature. 5083 Aluminum Alloy is usually with different status such as H111(5083 H111), O(5083 O), H12(5083 H12), H116(5083 H116), H321(5083 H321), H112(5083 H112) etc.

Alternative Material Names for 5083 Aluminum Alloy: AlMg4,5Mn, 3.3547.

Available Classification Society Certificates for 5083 Aluminum Alloy: ABS, DNV-GL, LR. NK, KR, RINA, BV, CCS, etc.

Chemical Composition(%):

Copper (Cu): ≤0.10;

Magnesium (Mg): 4.00 - 4.90;

Manganese (Mn): 0.40 - 1.00;

Iron (Fe): ≤0.40;

Silicon (Si): 0.0 - 0.40;

Zinc (Zn): 0.0 - 0.10;

Chromium (Cr): 0.05 - 0.25;

Titanium (Ti): ≤0.15;

Aluminium (Al): Balance;

Physical Properties:

Thermal Conductivity: 121 W/m.K

Melting Point: 570 °C

Thermal Expansion: 25 x10^-6 /K

Modulus of Elasticity: 72 GPa

Electrical Resistivity: 0.058 x10^-6 Ω .m

Density: 265 g/cm³

Application for 5083 Aluminum Alloy:

5083 Aluminum Alloy is with various applications such as marine sheet, aluminum alloy tank car body/tank body, automobile fuel tank, air storage tank, bus skin,C82 coal truck, automobile roof/bottom guard,LNG storage tank, mold, flange material,GIS high voltage switch shell, precision machining, etc

Notes for 5083 Aluminum Alloy:

5083 alloy belongs to AL-Mg alloy and anti-rust aluminum alloy series. 5083 alloy has also high strength, fatigue strength, high plasticity, besides that,5083 alloy can not be strengthened by heat treatment, when in semi-cold hardening process its plasticity is good, and when cold hardening the plasticity is lower.

Main Production Types for 5083 Aluminum Alloy:

TJC STEEL( TJC IRON& STEEL(GROUP) CO., LIMITED) are main manufacturer and distributor of 5083 Aluminum Alloy with kinds of types as 5083 Coils, 5083 Sheets, 5083 Tubes, 5083 Pipes, 5083 Pipe Fittings( Elbows, Tees, Stub Ends, Reducers, Flanges, etc)

Need more Information about 5083 Aluminum Alloy, pls call us or email to: info@tjcsteel.com.
