5086 is one kind of Al-Mg Aluminum Alloys,according to different content of Mg, the main grades of Al-Mg Aluminum alloy(from high Mg to low Mg) is 5005, 5252, 5251, 5050, 5052, 5754, 5083, 5056, 5086, etc. Same with 5083, 5086 aluminum alloy is with high strength, good performances in corrosion resistance too. When working in the temperate from 200℃ to 250℃, 5086 alloy is sensitive in property, besides, 5086 aluminum alloy is used to low temperature environment. When in application of seawater/ marine industries, 5086 alloy can be certified by Classification Society of ABS, DNV-GL, LR. NK, KR, RINA, BV, CCS, etc.

Alternative Material Names for 5086 Aluminum Alloy: UNS A95086.

5086 Aluminum Alloy is Popular with Status of O(5086 O), H112(5086 H112), H116(5086 H116), H111(5086 H111), H321(5086 H321), H32(5086 H32), H36(5086 H36), H38(5086 H38), etc.

Chemical Composition(%):

Si:0.00-0.40;

Fe： 0.000-0.500;

Cu:0.00-0.10;

Mg：3.5-4.5;

Zn：≤0.25;

Mn：0.20-0.7;

Ti ：≤0.15;

Cr：0.05-0.25;

Note：Single:≤0.05;Total:≤0.15.

Mechanical Properties:

Tensile Strength σb (MPa) : ≥240;

Conditional Yield Strength σ0.2 (MPa) : ≥95;

Elongation δ10 (%) : ≥10;

Elongation δ5 (%) : ≥12;

Note: Longitudinal Mechanical Properties of Pipe at Room Temperature; Sample Status 5086 H112.

Application for 5086 Aluminum Alloy:

5086 Aluminum Alloy is with high corrosion resistance, good weldability and medium strength occasions, which makes it popularly used for construction of fire pressure vessels, refrigeration units, television towers, installation of exploration equipment, transportation equipment, missile parts, armor, relevant marine industry parts, etc.

Notes for 5086 Aluminum Alloy:

5086 aluminum alloy in usual will be treated with annealed of 345℃, cooling method is air cooling. When cold working and forming to 5086 alloy, the status is normal with 'O' and sometimes could be with 'H38' and 'H36'.

Main Production Types for 5086 Aluminum Alloy:

TJC STEEL( TJC IRON& STEEL(GROUP) CO., LIMITED) are main manufacturer and distributor of 5086 Aluminum Alloy with kinds of types as 5086 Coils, 5086 Sheets, 5086 Tubes, 5086 Pipes, 5086 Pipe Fittings( Elbows, Tees, Stub Ends, Reducers, Flanges, etc)

Need more Information about 5086 Aluminum Alloy, pls call us or email to: info@tjcsteel.com.
