Grade 3 is one kind of commercially pure titanium, which contains less Titanium element than Grade 2 titanium, Grade 3 titanium’s mechanical properties and hardness data are higher than Grade 2. Besides, Grade 3 titanium’s plasticity and toughness performance is worse  when comparing with Grade 2 titanium.



Grade 3 Titanium Alloy is also named as UNS R50550, A55, BT1-0, JIS 3, Ti4, 2TA2, etc.

Density of Gr.3 Titanium: 4.51g/cm³.



Chemical Composition of Grade 3 Titanium(%):

Grade 3 Titanium	C	Fe	O	N	H	Ti
Max.	0,80	0,30	0,35	0,05	0,015	Bal.



Mechanical Properties for Grade 3 Titanium:

Grade 3 Titanium	Yield strength Rp0.2, MPa	Tensile strength Rm, MPa	Elongation [%]	Hardness [HRB]
Min.	379	448	18	160
Max.	552



TJC Steel can take kinds of third party inspection certificates such as DNV-GL, ABS, LR, BV, NK, RINA, TUV, SGS, etc for Grade 3 Titanium as per clients’ requests. In this way mill certificate will be comply with EN10204 3.2.



TJC Steel( owned by TJC Iron&Steel (Group) Co., Limited) is the most competitive manufacturer and supplier of Grade 3 Commercially Pure Titanium ( Titanium Sheets, Tubes, Elbows, Tees, , Reducers, Flanges and relevant pipe fittings. For more infos about Grade 3 Titanium Alloy, pls feel free to email us via info@tjcsteel.com.
