Hastelloy C-22 Alloy, UNS N06022 Alloy

Product No.：202191585931
Online Inquiry

Hastelloy C-22 is a versatile nickel-chromium-molybdenum-tungsten alloy that offers better overall corrosion resistance than other existing nickel-chromium-molybdenum alloys like Hastelloy C-276, C-4 and Inconel 625 alloys. Hastelloy C-22 alloy has excellent resistance to pitting, crevice corrosion and stress corrosion cracking. It has excellent resistance to oxidizing water media, including wet chlorine, nitric acid or a mixture of oxidizing acids containing chloride ions. Meanwhile, Hastelloy C-22 alloy also has the ideal ability to resist the reducing and oxidizing environments encountered during the process. Relying on this versatile performance, it can be used in certain special environments, or in a variety of production purposes in the factory applications. Hastelloy C-22 alloy has a good resistance to various chemical environments, including strong oxidizing substances, such as ferric chloride, copper chloride, chlorine, thermal pollution solution (organic and inorganic), formic acid, acetic acid, acetic anhydride, seawater and salt solution, etc. The ability of Hastelloy C-22 alloy to resist grain boundary precipitation formation in the welding heat affected zone makes it suitable for a variety of chemical process applications in the welding state.Hastelloy C-22 alloy is suitable for a variety of chemical process industries containing oxidizing and reducing media.The high content of molybdenum and chromium of Hastelloy C-22 makes the alloy be resistant to the corrosion of chloride ion, and the tungsten element further improves its corrosion resistance. Hastelloy C-22 is one of the few materials that can resist the corrosion of moist chlorine gas, hypochlorite and chlorine dioxide solution. This alloy has significant corrosion resistance to high concentration of salt chloride solution (such as ferric chloride and copper chloride).

Applications for Hastelloy C-22 Alloy:

Acetic acid/acetic anhydride; 2.Acid leaching; 3.Cellophane manufacturing; 4.Chlorination system; 5.Complex mixed acids; 6.Roller of electric galvanizing tank; 7.Expansion bellows; 8.Flue gas washer system; 9.Geothermal well; 10.HF furnace cleaner; 11.Incineration cleaner system; 12.Nuclear fuel regeneration; 13.Pesticide production; 14.Phosphoric acid production; 15.Pickling system; 16.Plate heat exchanger; 17.Selective filtration system; 18.Sulfur dioxide cooling tower; 19.Sulfonation system; 20.Pipe heat exchanger; 21.Hardfacing valve;etc.

Density for Hastelloy C-22 Alloy: 8.69g/cm³.

Chemical Composition of Hastelloy C-22 Alloy(%):

Name

Grade

UNS

W.Nr

Co(max)

P(max)

V(max)

C(max)

Mn(max)

Si(max)

S(max)

Ni- Cr- Mo Alloy

HASTELLOY C-22

N06022

2.4602

Rest

12.5-14.5

200-22.5

2.0-6.0

2.5

0.02

2.5-3.5

0.35-0.85

0.015

0.5

0.08

0.02

Mechanical Properties for Hastelloy C-22 Alloy:

Name	Grade	UNS	W.Nr	Condition/ Heat Treatment	Tensile Strength/ Mpa(min)	Yield Strength/ Mpa(min)	Elongation/ %(min)
Ni- Cr- Mo Alloy	HASTELLOY C-22	N06022	2.4602	Solution Annealed	690	310	45

TJC STEEL( TJC IRON& STEEL(GROUP) CO., LIMITED) are handling to produce and supply Hastelloy C-22 Alloy, N06022 Alloy products with main types of coils, sheets, tubes and pipe fittings such as flanges, elbows, tees, reducers, etc. All of Hastelloy C-22 Alloy, N06022 Alloy products can be certified by LR, KR, RINA, NK, BV, SGS, TUV, ABS, VL, etc; Mill certificate will be comply with EN10204 3.1 or EN10204 3.2.

For more details or assistance regarding Hastelloy C-22 Alloy, N06022 Alloy , pls contact TJC STEEL via info@tjcsteel.com.
